HMs DIY #1

You can create your own layout by creating a configuration string. To create a layout, download the latest designer version here: https://public.stattegg.info/HM_DIYD_3.8.3.zip http://public.stattegg.info/HMs_DIY_GUIDANCE.pdf http://public.stattegg.info/HMs_DIY_ANLEITUNG.pdf You can get more layouts and the latest fonts.txt on the github page here: https://github.com/hundsmiachn/Garmin_HMsDIY Because I want to keep this datafield and the app free for use I would be very grateful about a small donation to paypal.me/ErichJarz Example layouts can be found in the zip file. Please post any questions or bug reports in the forum thread: https://forums.garmin.com/developer/connect-iq/f/showcase/206277/hms-diy-1-6 !Thanks to mcinner1, Blackthrone666, christian888 and bodenseematze for providing their layouts! When you done with your layout, just press "Copy layout string to clipboard" and paste this string into the settings of the datafield in Garmin Express. Following value types are supported: Name of destination Name of next point Current date/time Timer time Current pause time Elapsed time Last lap time Current lap time ETA Time to dest ETA next p Time to next p Total pause time Current pace Avg. pace Max. pace Last lap avg. pace Current lap avg. pace Avg. pace (elapsed) Elapsed Dist. Dist. to destination Dist. to next point Dist. to coordinate Current lap Dist. Last lap Dist. Odometer Current speed Avg. speed Max. speed Last lap avg. speed Current lap avg. speed Avg. speed (elapsed) Current cadence Avg. cadence Max. cadence Current bike power Avg. bike power Max. bike power % FTP Normalized Power Last Lap NP Curr Lap NP Last Lap avg power Curr Lap avg power TSS Power zone number Time in power zone X % in power zone X Front derailleur index Front derailleur max Front derailleur size Rear derailleur index Rear derailleur max Rear derailleur size ANT BikeCadence * ANT BikeSpeedCadence * ANT BikeSpeed * ANT Shifting * ANT BikePower * ANT FitnessEquipment * ANT RunningDynamics * ANT BikeRadar status ANT BikeRadar battery ANT LightNet status ANT LightNet battery Current altitude Total ascent Total descent VAM total avg VAM current avg Min. altitude Max. altitude Gradient Min. gradient Max. gradient Avg. gradient Curr. heartrate Curr. heartrate %HFmax Avg. heartrate Max. heartrate Heartrate zone number Last lap avg HR Current lap avg HR Time in HR zone X % in HR zone X Calories spent Lap number Pressure Battery value GPS accuracy GPS high acc indicator Training effect Bike curr gear Temperature Pacer calc Avg. speed Pacer curr. ahead time Pacer target ahead time Pacer predicted time Pacer predicted pace Pacer total Avg. pace Pacer corrected Dist. Pacer offset indicator Free memory Datafield version App name Phone connected Start coordinates North Setting coordinates longitude, latitude, heading, sunrise, sunset

----------------------------------------------------------------------- 3.8.3 * fixed problem with backslash in configuration string ----------------------------------------------------------------------- 3.8.1 * switched to new SDK 8.3.0 * added devices: Approach S50, D2 Mach 2, Descent G2, Edge 550, Edge 850, Edge MTB, eTrex Touch, fēnix 8 Pro 47mm / 51mm / MicroLED, Forerunner 970, Forerunner 570 42mm, Forerunner 570 47mm, GPSMAP H1, Instinct 3 AMOLED 45mm, Instinct 3 AMOLED 50mm, Instinct 3 Solar 45mm / 50mm, Instinct Crossover AMOLED, Instinct E 40mm, Instinct E 45mm, Venu 4 41mm, Venu 4 45mm / D2 Air X15, Venu X1, vívoactive 6 ----------------------------------------------------------------------- 3.7.3 * fixed bug with distance to coordinate (imperial conversion) ----------------------------------------------------------------------- 3.7.1 * switched to new SDK 7.3.0 * added devices: Enduro 3, fenix 8 Solar 47mm, fenix 8 Solar 51mm, fenix 8 43mm, fenix 8 47mm / 51mm, fenix E
