SHN TxD II-E
· v7.0.3
About
** FREE TO USE ** only some functions are locked by PRO code, please see below.
Thanks to your great generosity and support, this wathcface will we free from july 1st 26,
you can donate now to get the PRO code or wait until july 1st to get PRO functions for free.
no refund will be made after july 1st.
Here is the PRO code: SHN23TxD2@wf:05
Please read the description and here (USER GUIDE): https://drive.google.com/drive/folders/1-L_EG0bXJsKdf1Lm6FNXFprqDecMELUW?usp=share_link.
A donation is for what I have done, not what I am going to do.
You donate for the device you have and accept this wf could not be available/compatible with your next device.
DONATION:
if you want to offer me a coffee, please do a donation through Paypal(avoid fees in selecting give to a friend): https://paypal.me/SHNSD
or Ko-Fi: https://ko-fi.com/shnsd (credit card possible)
but don't forget to put in the Paypal/Ko-Fi comment: SHN TacXIIE and your email address (if you want me to answer)
** COMPATIBILITY **
Please check your API level here: https://developer.garmin.com/connect-iq/compatible-devices/
ALTITUDE-PRESSURE-TEMPERATURE: not available for API inf2.4.0, and available for devices with sensors.
WEATHER from OpenWeatherMap: not available for API inf2.4.0 and for the Instinct Crossover due to memory limitation.
WEATHER from Garmin: available from API 3.2.0, some devices like F5+ can’t have it
Body Battery-Stress-Respiration-Time to recovery: available from API 3.3.0
Instinct Crossover: Please see the user guide, due to memory limitation some functions are not available, no digital main time for crossover.
** SUNEVENTS (POSITION) **
A position is needed to calculate it.
for compatible devices, GPS from mobile is used to calculate it,
but overridden by the GPS from your device if you use it so that it can be calculated without mobile if needed.
To get a GPS signal from your device: open an activity (without CIQ data filed) and wait for green GPS signal, then go back to the watchface.
!!!!!!!! Sunset/Sunrise are not the same thing as Dusk/Dawn !!!!! if you found an offset turn off "Dusk/Dawn" option.
Tips: if you put Sun Event on Ring data, put Current Time on Arrow Data to see where you are on the timelapse.
** WEATHER**
- Only available from CIQ 2.4.0 devices
- For compatible device (from CIQ 3.2.0) Garmin weather can be used, to use Garmin weather, just let the API key field empty.
- For others or if you prefer weather from OpenWeatherMap, please get an API here: https://openweathermap.org/price
subscribe for a free account, you will get the API key, put it in the settings.
After the API creation, it may take up to 2 hours to be activated.
- In order to have both of them work, your device needs to know your position, for CIQ3.2.0+, the position from your mobile is used,
For infCIQ3.2.0, you need to get a GPS signal (and every time you move far), see SunEvent section.
For both of them:
-Make sure PRO code is right entered.
-Make sure Garmin Connect App (Android/IOS) runs on the background.
-Make sure Garmin Connect app has all permissions (background/Location etc).
Permissions can be cleared in case of IOS/Garmin connect updates.
-Make sure GPS is turned “on” on your phone and your phone has access to the internet.
See SUNEVENT (POSITION) section.
-Make sure your device is well connected with your phone.
AQI/UVI: provided by open-meteo.com
see user guide
FONT SIZE: please see the user guide, there is a note about this.
What's new
[PLEASE READ THE DESCRIPTION]
If you like it, please consider a review/rate, that will help me a lot and encourage me to improve it
USER GUIDE: https://drive.google.com/drive/folders/1-L_EG0bXJsKdf1Lm6FNXFprqDecMELUW?usp=share_link
---
Known issues:
- for devices from 14.31 fw (F7,EPIX etc): the gesture detection is broken by this update
unfortunately it is not on my side and can't do anything but wait for Garmin fix. Workaround: put backlight on gesture to always
- Garmin dropped down Location name: https://forums.garmin.com/developer/connect-iq/i/bug-reports/cannot-get-location-of-garmin-weather-for-fenix8-series-devices
---
7.0.3
ADDED: devices
FIXED: issue with custom progress bar color and move bar
FIXED: issue with crossed min and mainTimeBackground
---
7.0.0
ADDED: Background image, only from CIQ5.1.x (please see updated user guide)
ADDED: Extra line "V": weather2 only from CIQ5.1.x and Garmin Weather (pressure, cloud cover, visi,UV)
FIXED: Graph color issue
---
6.8.1
ADDED: left/right icon: Floors - VO2 - Respiration rate
ADDED: Running/Cycling distance 2 (may take activities recorded on another device)
ADDED: Main Time background color
Custom color for it = 15, Tactical color move to 20
---
6.5.1
ADDED: AOD level (from 2: API 5 devices)
ADDED: beta: Extra Line L: active kcal - Total [expected]
---
6.3.0
ADDED: Stress Score data, only from API 5.0.0, might be more accurate than stress history
Stress Score does not have history so the "Graph" is a bar according current score (0-100)
see here for compatible devices:https://developer.garmin.com/connect-iq/api-docs/Toybox/ActivityMonitor/Info.html#stressScore-var
---
6.1.0
ADDED: extra line "B" for activities:
Steps/pushes* - Distance – floors climbed* - Daily Active minutes* - Kcal (*for compatible devices)
---
6.0.0
ADDED: AQI/UVI data
free to use,no API key needed, provided by open-meteo.com
---
5.3.0
ADDED: hour (12hr format) and minutes added on Arrows data, thanks to Hayden James for the Idea.
---
5.2.0
ADDED: Moon Ic 2 (icon + illumination %)
IMPROVED: German translation, thanks to Florian
IMPROVED: Slovak translation, thanks to Josef
---
5.0.0
ADDED [PRO]: Sun Event Angle option:
use it if you need either Astronomic Dawn/Dusk or Nautic Dawn/Dusk or Golden hour or Blue hour,
let it to 0 if you use "regular" Sunrise sunset or Dusk/Dawn (civilian hour)
ADDED: Total weekly running/cycling/swimming time
put 0 to have on extra line: Total weekly dist - Total weekly time - VO2max (1 for cycling, 2 for swimming).
In order to save battery and avoid lag on some devices, those data is refresh every 15min.
---
4.11.2
ADDED: Slovakian settings, huge thanks to Tomáš D!
---
4.0.0
ADDED: [PRO] Complications system
Some apps (from the IQ store) can publish data, Complication system allow the watchface to retrieve those data and display them on it.
please see updated user guide
---
3.6.0
ADDED: [PRO] Arrow: Find direction function:
aim the sun with the arrow then your 12 o'clock device will show you the north (south for the southern hemisphere)
---
3.3.4
ADDED [PRO] Extra line Day Count (J=custom font / K=native font)(not available for FR45-GS2-CrossOver)
use custom Title to set the event name: -5:EventName (see user guide)
---
3.0.0
ADDED [PRO] Arrow 2 (works like arrow1, not available for FR45,GS2 and Instinct CO)
ADDED [PRO] Custom Progress bar color (please see the updated user guide, to see how it works, from CIQ2.4.0)
ADDED [PRO] Custom Title text (please see the updated user guide, to see how it works, not available for FR45,GS2 and Instinct CO)
---
2.1.0
ADDED: Settings translations: DEU-RUS-SPA
huge thanks to: Florian - Владимир - Kike
ADDED: [PRO] Touch function, for compatible devices (from CIQ4.2.0 with touch screen)
---
1.4.1
ADDED: PRO extra line: Weather forecast (time icon temp° Cloud(rain for gw) trend windSpeed trend
for OWM users, weather update time has to be set at min 10min and it may take up to 15min to get the forecast
..
